10 lb. Semi-Recessed Extinguisher Cabinet

SKU :
10SR
PRODUCT SPECIFICATIONS
DESCRIPTION
PRODUCT SPECIFICATIONS

Elite Series 9 x 24 x 6 Semi Recessed Cabinet accommodates 10 lb extinguishers.
Tub 22 ga. (0.75 mm)
Flush SS Paddle Latch

• 16 ga. Door & Trim (1.5 mm) & 22 ga. Tub (.75 mm)
• 2” turnback (return frame) allows for installation in a 4” wall
• Welded tub and front
• Full viewing panel (5” x 20” acrylic panel, #A520 sold separately)
• Grey baked enamel finish
• Glass clips included
• Full-length semi-concealed piano hinges
• Flush stainless steel door paddle latches

add to quote
PRODUCT SPECIFICATIONS
PRODUCT SPECIFICATIONS
SUPPORTING DOCUMENTS
SKU Applications Style Material Colour Ship Weight (lbs) Turnback (In.) Min Wall Depth (In.) Front Type Glass Size (In.) Door & Trim Constuction
10SR 10 lb. Dry Chem Extgrs Semi-Recessed Steel Grey 15.5 2 4 Full Glass 5 X 20 16 ga. (1.5 mm) Welded tub and front
5SR 5 lb. Dry Chem Extgrs Semi-Recessed Steel Grey 9.1 1 4 Full Glass 4 x 13 16 ga. (1.5 mm) Welded tub and front
5FR 5 lb. Dry Chem Extgrs Fully-Recessed Steel Grey 9.1 0.25 5 Full Glass 4 x 13 16 ga. (1.5 mm) Welded tub and front
10FR 10 lb. Dry Chem Extgrs Fully-Recessed Steel Grey 15 0.25 6 Full Glass 5 X 20 16 ga. (1.5 mm) Welded tub and front
BC1430 20 lb. Dry Chem Extgr, 10 lb CO2 Semi-Recessed Steel Grey 32 1 4 Bubble Canopy 10.75 x 27 14 ga. Welded tub and Adjustable front
5SRSS 5 lb. Dry Chem Extgrs Semi-Recessed Stainless Steel 304-#4 Satin 9.1 1 4 Full Glass 4 x 13 16 ga. (1.5 mm) Welded tub and front
10SRSS 10 lb. Dry Chem Extgrs Semi-Recessed Stainless Steel 304-#4 Satin 15.5 2 4 Full Glass 5 X 20 16 ga. (1.5 mm) Welded tub and front
10SRW 10 lb. Dry Chem Extgrs Semi-Recessed Steel White 15.5 2 4 Full Glass 5 X 20 16 ga. (1.5 mm) Welded tub and front
BC1430W 20 lb. Dry Chem Extgr, 10 lb CO2 Semi-Recessed Steel White 32 1 4 Bubble Canopy 10.75 x 27 14 ga. Welded tub and Adjustable front
