3000 PSI Gauge for N100 and N200QR Valve
SKU: G3000
3/4” Quick Release Nitrogen Valve with 3000 PSI Gauge for Dry Chemical Wheeled Units
This valve is intended for use on Department of Transportation (DOT) cylinders, excluding Type DOT-4L cylinders, charged with nitrogen not exceeding 2,200 PSI. The valves include a listed
high pressure gauge. Each valve is provided with a rupture disc device, Type CG-1, which is a non-reclosing pressure-relief device actuated by inlet static pressure, and designed to release excess
pressure of a normal charged cylinder, when exposed to abnormal conditions, by bursting a pressure containing disk.
Model N200QR is designed to burst at a maximum pressure of 3,360PSI at 160 Degree Fahrenheit.
- UL Listed (File# MH13426)
- 3/4" Quick Release Nitrogen Valve
- 3,000 PSI Gauge
- Burst Pressure 3,360 PSI
- Maximum working pressure 2,200 PSI
- Outlet connection: female CGA 580 (0.965-14 NGO R.H. Thread)
- Inlet base connection: Male 3/4 -14 NGT
